Jackson Goldstone's Santa Cruz V10

This bike check covers Jackson Goldstone's Santa Cruz V10, a downhill build with 17 parts listed below by slot.

Listed parts include a Fox 40 Factory GRIP X2 fork, a Fox DHX2 Factory shock, a Shimano Saint M820 drivetrain and Shimano Saint M820 brakes. Tires are Maxxis Assegai up front and Maxxis Minion DHR II out back.

Part names and setup notes are as recorded in the BuildMTB Archive. Clone the build to start your own from this spec, with compatibility checks on every part you swap.

Prices and buy links
Jackson Goldstone's Santa Cruz V10

Jackson Goldstone's Santa Cruz V10 parts list

Frame
Santa Cruz
V10
V10: Size M, centered reach, long chainstay, mullet 29"/27.5"
Fork
Fox
40 Factory GRIP X2
40 Factory: 200mm, 29", 89 psi, 2 volume spacers, custom tune
Shock
Fox
DHX2 Factory
DHX2 Factory Coil: 475 lb/in spring, custom tune
Groupset
Shimano
Saint M820
Shimano prototype drivetrain: 36T ring, tungsten-ballast spindle, custom 16° OChain
  • Rear derailleurShimano Saint RD-M820 (DH, Short Cage)
  • ShifterShimano Saint SL-M820-I (Direct Mount)
  • CassetteShimano HG-500 11-32t 10-Speed
  • ChainShimano CN-HG54 10-Speed (116 links)
  • CranksetShimano Saint FC-M825 (36T, 165mm, 83mm BB)
Front Wheel
Reserve
30DH Carbon
30|DH Carbon: Chris King hub, 29"
Rear Wheel
Reserve
30DH Carbon
30|DH Carbon: Chris King hub, 36T ratchet, 27.5"
Brakes
Shimano
Saint M820
Shimano prototype brakes: levers nearly flat, tight bite point
Front Rotor
Shimano
RT-6B750
RT-6B750: 200mm F&R, 2.2mm thick
Handlebar
OneUp
Carbon V2
Carbon V2: 35mm rise, cut to 775mm
Stem
OneUp
Direct Mount
Direct Mount: 45mm
Headset
Santa Cruz
V10 Reach Adjust cups
Reach Adjust cups, centered: IS41/IS41
Seatpost
Burgtec
Xpress Alloy
Xpress Alloy: 31.6mm
Saddle
Burgtec
The Cloud DH
Grips
OneUp
Goldstone Signature
Pedals
Crankbrothers
Mallet DH
Mallet DH: clipless, tall pin setup
Front Tire
Maxxis
Assegai
Assegai: 29"×2.5" New DH casing, 21-23 psi
Rear Tire
Maxxis
Minion DHR II
Minion DHR II: 27.5"×2.4" New DH casing, 25-28 psi
Make it yours

Load Jackson Goldstone's Santa Cruz V10 into the builder as a new build, then swap parts to fit your riding and budget.
